SPECIFICATIONS
| UNIT WEIGHT |
Unit: 18.6 kg (41 lb) |
|---|---|
| METHOD | ASTM D3829, ASTM D4684, ASTM D6821, ASTM D6896, SAE J300 |
| DIMENSIONS (W X D X H) |
Unit: 31.7 cm × 26.0 cm × 48.9 cm (12.5 in × 10.25 in × 19.25 in) |
| SHIPPING DIMENSIONS (W X D X H) |
Box 1: 88.9 cm × 88.9 cm × 88.9 cm (35 in × 35 in × 35 in) |
| SHIPPING WEIGHT (WITH ALL ITEMS) |
Box 1: 68.0 kg (150 lb) |
| MAXIMUM THROUGHPUT | 9 samples per test cycle |
| SAMPLE CAPACITY | 9 |
| TEMPERATURE RANGE AND ACCURACY | −5 °C to −40 °C, ± 0.1 °C |
| MINIMUM SAMPLE/SOLVENT VOLUME | 10 mL per test |
| OPERATING CONDITIONS | 15 °C to 30 °C, 10% to 75% relative humidity (non-condensing), Installation Category II; Pollution Degree 2 |
| ELECTRICAL SPECIFICATIONS | 100 Vac, 50/60 Hz; 115 Vac, 50/60 Hz; 230 Vac, 50/60 Hz; 400 watts power consumption (unit); 1100 watts power consumption (AWHE) |
| COMPLIANCE | CE Mark; EMC directive (2004/108/EC); Low voltage directive (2006/95/EC); HI-POT (1900 Vdc, 60 sec.); ROHS |
