Danh mục thiết bị Greisinger - Đức

(1 đánh giá)

Mã SP: Greisinger
Vui lòng gọi

Xuất xứ :Greisinger - Đức

Nơi rao bán :Toàn quốc

Tình trạng :Mới 100%

Ngày cập nhật :18-05-2018 10:01:18

Bảo hành :12 tháng

GTH175PT Greisinger, thiết bị phòng thí nghiệm, đo nhiệt, đo áp suất, đo độ ẩm, PH, khí oxy, co2, đo tiếng ồn, đo tốc độ gió, đo độ nghiêng

LIÊN HỆ VỚI NGƯỜI BÁN

THIẾT BỊ CÔNG NGHIỆP-TỰ ĐỘNG HÓA

D3 Miến Nổi, Đinh Tiên Hoàng, Phường 3, Quận Bình Thạnh

0938214498

canh.ans@ansvietnam.com

http://webthietbicongnghiep.com

Ghi chú: GianHangVN không trực tiếp bán sản phẩm, vui lòng liên hệ trực tiếp với người bán bên trên.
ANH NGHI SƠN LÀ ĐẠI LÝ PHÂN PHỐI Greisinger VIETNAM

Xuất Xứ: Greisinger Germany

Listcode: Greisinger Vietnam

Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Pressure Converter
Type: UNICON-P-1-3-3-11
Display: LCD-dot matrix, 3.8 mm characters
Model: Output 4..20 mA, 2-wire 7.5..30 V DC
Measuring range: ± 30 mbar rel. (max. 300 mbar)
Process medium: dry and non aggressive gases
Outputs: 2 Transistor 14..30 V DC, max. 60 mA
Process port: 6 mm Schott glands
Operating temperature: -10..+55 °C
Field case: with snap lid, 1 x M20x1.5
Dimensions: 100x100x60 mm
Protection class: IP65, terminals IP20 acc. to BGV A3
Option: [11] extended burst pressure (max. 3 bar)
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Pressure Converter
Type: UNICON-P-1-3-3-11
Display: LCD-dot matrix, 3.8 mm characters
Model: Output 4..20 mA, 2-wire 7.5..30 V DC
Measuring range: ± 30 mbar rel. (max. 300 mbar)
Process medium: dry and non aggressive gases
Outputs: 2 Transistor 14..30 V DC, max. 60 mA
Process port: 6 mm Schott glands
Operating temperature: -10..+55 °C
Field case: with snap lid, 1 x M20x1.5
Dimensions: 100x100x60 mm
Protection class: IP65, terminals IP20 acc. to BGV A3
Option: [11] extended burst pressure (max. 3 bar)
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Code: GOO370 (GOO 370)
Oxygen sensor for GMH369x
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Barometer
Type: GPB3300-GE
Variant: Greisinger
Measuring range: 300...1100 hPa
Accuracy: ±0,2 mbar
Sensor: Piezoresistive pressure sensor
Working temperature: -25 .. +50°C
Power supply: 9V Battery
(GPB 3300)
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Flow switch
Type: FW1-015GP006-1
Nominal diameter: DN 015
Connection: Female thread G 1/2
Housing: POM GV
Working pressure: PN 10
Interior parts: POM GV / POM / 1.4310 /Hartferrit
Seal: NBR
Media temperature: -20..+90 °C
Ambient temperature: -20..+70 °C
Adjustable range H2O: up to  6 l/min H2O
Switch head: Plastic PC
Adjustment: Elongated hole
El. connection: cable 1 m 2xAWG20 UL/SCA sw AWM Style 2464
El. contact: Reed switch UL-Certificate
Max. contact load: 100 V DC 0,5 A, 10 W (250 VDC max. voltage)
Wiring: SPST NO - no. 0.446
Protection: IP 67
Flow direction: Horizontal, from left
Specification: Klüver, Nr. 95140538.00
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Flow switch
Type: FW1-015GP006-1
Nominal diameter: DN 015
Connection: Female thread G 1/2
Housing: POM GV
Working pressure: PN 10
Interior parts: POM GV / POM / 1.4310 /Hartferrit
Seal: NBR
Media temperature: -20..+90 °C
Ambient temperature: -20..+70 °C
Adjustable range H2O: up to  6 l/min H2O
Switch head: Plastic PC
Adjustment: Elongated hole
El. connection: cable 1 m 2xAWG20 UL/SCA sw AWM Style 2464
El. contact: Reed switch UL-Certificate
Max. contact load: 100 V DC 0,5 A, 10 W (250 VDC max. voltage)
Wiring: SPST NO - no. 0.446
Protection: IP 67
Flow direction: Horizontal, from left
Specification: Klüver, Nr. 95140538.00
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Code: VM-040GR040A
VM-. ..GR: Flow
040: DN 40 - G 1 1/2
G : Female thread
R : red Bronze
040 : 10-40l/min
A: Optional for ATEX
(for switching head ATEX A-V2 or A-V3
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam GSH8922 (GSH 8922)
Phonometer
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam AirCheck 100(118930)
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam GOX100 (GOX 100)
Air Oxygen measuring device
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Code: GMH 3330
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Code: TFS 0100E
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Code: Universal case for device
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Model: GMH3750 (GMH 3750)
Precision thermometer with analog output and logger, Pt100
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Model: GMH3750 / SET1 (GMH 3750 / SET1)
GMH3710 incl. GTF401 and WPT3
[GTF401: Immersion probe, Pt100 4-wire
WPT3 Calibration certificate - Temperature (-20 / 0 / 70°C)]
Greisinger – Honsberg – Martens – Imtron - GHM Vietnam Correct: GTH175PT-K-00-GE
Precision pockert-thermometer
Type: GTH175PT
