Động cơ các loại xe FAW- Howo- Dongfeng- CamC- Jac,.... Hyundai, Samsung,...Man, Volvo,....

(1 đánh giá)

Mã SP: 115909
Vui lòng gọi

Xuất xứ :Nhập khẩu chính hãng.

Nơi rao bán :Toàn quốc

Tình trạng :Mới 100%

Ngày cập nhật :06-06-2018 22:57:45

Bảo hành :6 tháng

Nhập khẩu và phân phối động cơ của các loại xe có mặt tại Việt Nam:
- Trung Quốc: Faw, Howo, Dongfeng, Jac, Camc,....
- Hàn Quốc: Samsung, Hyundai, ....
- Nhật Bản: Hino, Isuzu, ....
- Đức: Man, ...
......
......

LIÊN HỆ VỚI NGƯỜI BÁN

CÔNG TY TNHH HD VINA QUỐC TẾ

Xóm Trám- Thôn 3- Xã Ba Trạ- Huyện Ba Vì- Thành Phố Hà Nội

098 616 3238

otoviet368@gmail.com

http://xevamay.com

Ghi chú: GianHangVN không trực tiếp bán sản phẩm, vui lòng liên hệ trực tiếp với người bán bên trên.
  * Nhập khẩu và phân phối động cơ của tất cả các loại xe có mặt tại Việt Nam:
- Trung Quốc: Faw, Howo, Dongfeng, Jac, Camc,....
- Hàn Quốc: Samsung, Hyundai, ....
- Nhật Bản: Hino, Isuzu, ....
- Đức: Man, ...
......
......
* Sản phẩm được nhập khẩu, phân phối chính hãng và có bảo hành.
Điện thoại liên hệ: 098 616 3238




CA6DN1 13L

Model CA6DN1-39E3 CA6DN1-42E3 CA6DN1-46E3
Type 6 cylinders, in line, director injection, turbocharged inter-cooling, electronic control common rail
Bore×Stroke (mm×mm) 131×155
Valve number 4 Valves/cylinder
Total displacement (L) 12.53
Rated power/speed (kW/r/min) 300/1900 322/1900 352/1900
Max torque/speed (N. m/r/min) 1750/1200-1400 1900/1100-1200 2100/1100-1200
Min. fuel consumption at full load (g/kW. h ) ≤200
Smoke (FSN) ≤1.8
Noise dB(A) ≤97
Emission (TAS) EuroⅢ
Net weight (kg) 1200 (not include clutch, inter-cooler)

CA6DM2 11L

Model CA6DM2-35E3 CA6DM2-37E3 CA6DM2-39E3 CA6DM2-42E3
Type 6 cylinders, in line, director injection, turbocharged inter-cooling, electronic control common rail
Bore×Stroke (mm×mm) 123×155
Valve number 4 Valves/cylinder
Total displacement (L) 11.04
Rated power/speed (kW/r/min) 270/1900 285/1900 300/1900 322/1900
Max torque/speed (N.m/r/min) 1650/1100-1400 1700/1100-1400 1800/1100-1400 1900/1100-1400
Min. fuel consumption at full load (g/kW. h ) ≤195
Smoke (FSN) ≤1.8
Noise dB(A) ≤95
Emission (TAS) EuroⅢ
Net weight (kg) 1000 (not include clutch, inter-cooler)

CA6DL2 8.6L

Model CA6DL2-33E3 CA6DL2-35E3 CA6DL2-37E3
Type 6 cylinders, in line, director injection, turbocharged inter-cooling, electronic control common rail
Bore×Stroke (mm×mm) 112×145
Valve number 4Valves/cylinder
Total displacement (L) 8.6
Rated power/speed (kW/r/min) 258/2100 270/2100 288/2100
Max torque/speed (N. m/r/min) 1500/1200-1500 1500/1300-1500 1650/1200-1500
Min. fuel consumption at full load (g/kW. h ) ≤195
Smoke (FSN) ≤1.7
Noise dB(A) ≤96.5
Emission (TAS) EuroⅢ
Net weight (kg) 830 (not include clutch, inter-cooler)

CA6DL1 7.7L

Model CA6DL1-26E3 CA6DL1-29E3 CA6DL1-32E3
Type 6 cylinders ,in line, director injection ,turbocharged inter-cooling ,electronic control common rail
Bore×Stroke (mm×mm) 110×135
Valve number 4 Valves/cylinder
Total displacement (L) 7.7
Rated power/speed (kW/r/min) 203/2300 224/2300 239/2300
Max torque/speed (N. m/r/min) 1050/1300-1700 1150/1300-1700 1250/1300-1500
Min. fuel consumption at full load (g/kW. h ) ≤198
Smoke (FSN) ≤1.7
Noise dB(A) ≤96.5
Emission (TAS) EuroⅢ
Net weight (kg) 780 not include clutch, inter-cooler)

CA4DL1 5L

Model CA4DL1-18E3 CA4DL1-19E3 CA4DL1-20E3 CA4DL1-21E3
Type 4 cylinder, in line, director injection, turbocharged inter-cooling, electronic control common rail
Bore×Stroke (mm×mm) 110×135
Valve number 4 Valves/cylinder
Total displacement(L) 5.133
Rated power/speed (kW/r/min) 143/2300 147/2300 159/2300 163/2300
Max torque/speed (N.m/r/min) 650/1300-1700 650/1300-1700 780/1300-1700 780/1300-1700
Min. fuel consumption at full load (g/kW. h ) ≤195
Smoke (FSN) ≤2.0
Noise dB(A) ≤96.5
Emission (TAS) EuroⅢ
Net weight (kg) 600 (not include clutch, inter-cooler)

CA6DF3 6.5L

Model CA6DF3-16E3 CA6DF3-18E3 CA6DF3-20E3 CA6DF3-22E3 CA6DF3-24E3
Type 6 cylinders director injection turbocharged inter-cooling electronic control common rail
Bore×Stroke (mm×mm) 107×125
Total displacement(L) 6.74
Rated power/speed (kW/r/min) 125/2300 143/2300 155/2300 171/2300 188/2300
Max torque/speed (N. m/r/min) 580/1300-1500 680/1300-1500 760/1300-1500 860/1300-1500 935/1300-1500
Min. fuel consumption at full load
(g/kW. h )
≤205
Smoke (FSN) ≤1.7
Noise dB(A) ≤97
Emission (TAS) EuroⅢ
Net weight (kg) 700 (not include inter-cooler)

CA6DF2 7L

Model CA6DF2-22 CA6DF2-23 CA6DF2-24 CA6DF2-26 CA6DF2-28
Type 6 cylinders in line director injection turbocharged inter-cooling
Bore×Stroke (mm×mm) 110×125
Total displacement(L) 7.127
Rated power/speed (kW/r/min) 171/2300 180/2300 188/2300 203/2300 218/2300
Max torque/speed
(N.m/r/min)
780/1300 850/1300 890/1400 930/1400 960/1400
Min. fuel consumption at full load (g/kW. h ) 205 210 208
Smoke (FSN) ≤1.8
Noise dB(A) ≤98
Emission (TAS) EuroⅡ
Net weight (kg) 700 (not include inter-cooler)

CA4DF3 4.75L

Model CA4DF3-13E3 CA4DF3-14E3 CA4DF3-15E3 CA4DF3-17E3
Type 4 cylinders in line director injection turbocharged inter-cooling electronic control common rail
Bore×Stroke (mm×mm) 110×125
Total displacement(L) 4.752
Rated power/speed (kW/r/min) 101/2500 109/2500 116/2300 132/2300
Max torque/speed (N.m/r/min) 450/1400 450/1400 530/1400 600/1400
Min. fuel consumption at
full load (g/kW. h )
≤205
Smoke (FSN) ≤2.0
Noise dB(A) ≤97
Emission (TAS) EuroⅢ
Net weight (kg) 550 (not include inter-cooler)

CA4DF2 4.75L

Model CA4DF2-13 CA4DF2-14 CA4DF2-16 CA4DF2-17
Type 4 cylinders in line director injection turbocharged inter-cooling
Bore×Stroke (mm×mm) 110×125
Total displacement(L) 4.752
Rated power/speed (kW/r/min) 101/2500 109/2500 124/2300 132/2300
Max torque/speed (N. m/r/min) 390/1500 490/1400 560/1400 580/1400
Min. fuel consumption at full load (g/kW. h ) ≤208
Smoke (FSN) ≤2.0
Noise dB(A) ≤98
Emission (TAS) EuroⅡ
Net weight (kg) 480 (not include clutch, inter-cooler)

CA4DX 3.8L

Model 4DX23-110E3 4DX23-120E3 4DX23-130E3 4DX13-100E3 4DX13-110E3 4DX13-120E3
Type 4 cylinders, in line, director injection, turbocharged inter-cooling ,electronic control unit pump
Bore×Stroke(mm×mm) 102×118 100×118
Total displacement(L) 3.857 3.707
Rated power/speed (kW/r/min) 83/2800 90/2800 101/2800 78/2800 83/2800 90/2800
Max torque/speed (N.m/r/min) 324/1800-2000 343/1800-2000 380/1800-2000 296/1800-2000 324/1800-2000 324/1800-2000
Min. fuel consumption at full load (g/kW. h ) ≤205
Smoke (FSN) ≤2.26
Noise dB(A) ≤96.5
Emission (TAS) EuroⅢ
Net weight (kg) 340

CA4DW 2.5L

Model 4DW81-50 NG2 4DW82-71 NG2 4DW93-84 NG2
Type 4 cylinders, in line,water-cooling、SDi 4 cylinders, in line, water-cooling turbocharge 4 cylinders, in line,water-cooling turbocharged inter-cooling
Bore×Stroke (mm×mm) 85×95 90×100 90×100
Total displacement(L) 2.156 2.54 2.54
Rated power/speed (kW/r/min) 37 / 3200 52/2900 64/2900
Max torque/speed (N. m/r/min) 127/ 2000 -2200 197/1900-2100 220/1900-2100
Min. fuel consumption at full load (g/kW. h ) ≤235 ≤245 ≤225
Smoke (FSN) ≤2.0
Noise dB(A) ≤96.5
Emission (TAS) EuroⅡ
Net weight (kg) 205 210 210

CA4DB 2.0L

Model CA4DB
Type In-line four cylinders, Water cooled, DOHC
Bore*Stroke (mm) 84*90
Total displacement(L) 1.995
Compression ratio 17.5
Power rating (kW/r/min) 100/4000
Max.torque (Nm/r/min) 320/1800-3000
Min.fuel consumption ratio 210
Noise (1m) dB(A) 103.7
Net weight (kg) 160
Overall dimension (L*W*H)(mm) 545×689×647
Emission standard EURO IV
