- Basic data
- Series420
- Operating principleScanning principle with background suppression
-
Optical data
- Operating range0.1 ... 1 m
- Shape of sound lobeWide
- Direction of beamFront
-
Timing
- Switching frequency10 Hz
- Response time50 ms
-
Electrical data
- Performance data
- Supply voltage12 ... 30 V, DC
-
Inputs
- Number of teach inputs1 Piece(s)
-
Outputs
- Number of digital switching outputs1 Piece(s)
- Switching output 1
- Switching elementTransistor, NPN
- Switching principleNC (normally closed)
- Performance data
-
Connection
- Connection 1
- Type of connectionConnector
- Thread sizeM8
- MaterialPlastic
- No. of pins4 -pin
- Connection 1
-
Mechanical data
- DesignCubic
- Dimension20 mm x 42 mm x 15 mm
- Housing materialPlastic, PE
- Net weight10 g
-
Operation and display
- Operational controlsTeach button
-
Environmental data
- Ambient temperature, operation-10 ... 60 °C
-
Certifications
- Degree of protectionIP 67
- Protection classIII
- Certificationsc UL US
- Standards appliedIEC/EN 60947-5-2
-
Classification
- Customs tariff number85365019
- eCl@ss 8.027272803
- eCl@ss 9.027272803
- ETIM 5.0EC001849
