Tên thiết bị:  PSI Audio A214-M Center-channel Studio Monitor

Model:   A214-M

Thương hiệu:  PSI Audio

Tình trạng: đóng hộp, hàng mới

Hình ảnh thiết bị như hình chụp

Product Highlights

  • 2 x 5.8" Woofers and 3.9" Tweeter
  • Class-G Amplifier: Bi-Amp 120W + 40W
  • Frequency Response: 53 Hz to 23 kHz
  • Max SPL: 108 dB
  • Balanced XLR Input
  • Designed for Center Channel Surround Use
  • AOI, ALG, CPR, PSC Technology
  • For Surround Monitoring Applications
  • Volume and Roll-Off Controls



PSI AUDIO A214-M overview





The single, red PSI Audio A214-M is a powered, center-channel monitor designed to be tonally balanced with high-resolution detail and efficient transient response for accuracy in surround setups. The speaker is versatile enough to be used for standard near-field studio monitoring applications. The bi-amplifier delivers 120W to the two 5.8" woofers and 40W to the 3.9" tweeter, which combine to provide a frequency response of 53 Hz to 23 kHz at an SPL of 108 dB with a single speaker and 119 dB per pair.

The amplifier output also features the AOI output stages, while the active crossover with integrated CPR delivers an impulse behavior with accurate stereo imaging. The crossover is also optimized for maximum phase coherence, projecting a wide horizontal and vertical listening area.

The rear panel offers a balanced XLR input and features a volume control and a roll-off control for optimizing the low frequencies for standalone use or when using an optional subwoofer. The PSI Audio A214-M ships with a power cord, anti-slippage stickers, and an individual frequency-response diagram.



  • High SPL in a compact cabinet
  • Flat frequency response
  • Real symmetrical directivity
  • Class-G low-temperature amplifier stage
  • Optional metal bracket
  • Protection circuits with overload indicator
  • True balanced input
  • Designed for stereo and multi-channel monitoring
  • Magnetically shielded for use near video monitors
  • Phase and amplitude response compatible with all PSI Audio monitors
Adaptive Output Impedance (AOI)
The AOI system is made up of a system that detects the movement of the membrane and the coil, as well as a filtered counter reaction. This is then tuned to achieve the ideal dampening rate for each frequency
Acoustic Load Guide (ALG)
The ALG is used in all regular 2-way and 3-way PSI Audio speakers. The shape and dimensions of the waveguide used in PSI Audio's custom tweeter is specially designed to optimize directivity, as well as maximize sound-pressure level, and extend bandwidth
Compensated Phase Response (CPR)
The CPR system is made up of several all-pass filters, each acting in a specific range. Combined, they create a compensated phase response, which provides a constant group delay that is kept to the bare minimum through the entirely analog technology
Phantom Standby Control (PSC)
The PSC technology enables to remote activation and deactivation of the standby mode of your loudspeakers via the signal cable


PSI AUDIO A214-M specs

Power Power RMS: 120 W + 40 W
Program Power: 160 W
Input Impedance Sym, 10 kOhms
Sensitivity Sensitivity for 100 dB @ 1 m: 0.775 V
Signal to Noise Ratio (SNR) 96 dBA
SPL Continuous Max SPL @ 1 m: 108 dB (single)
Program Max SPL @ 1 m: 119 dB (pair)
Input Overload 24 Vpp
Frequency Response Response at -6 dB: 53 Hz to 23 kHz
Tolerances: ±2.0 dB (60 Hz to 20 kHz)
Distortion (THD) Less than 1.2% (120 Hz to 12 kHz)
Phase Deviation Phase Tolerances: ±45° (270 Hz to 20 kHz)
Dispersion Dispersion (P.N. 4 to 16 kHz) at -6 dB: 90° x 60° (H x V)
System 2-way
Crossover Frequency 1.8 kHz
Woofer Woofer's External Diameter: 5.8" / 147 mm
Diaphragm: 4.1" / 104 mm
Tweeter Tweeter's External Diameter: 3.9" / 100 mm
Diaphragm: 1" / 25 mm
Connector XLR-F: 3-pin
Wiring Scheme Signal Input: 1=GND, 2=(+), 3=(-)
Material of Construction MDF
Voltage 115/230 VAC (50 / 60 Hz)
Power Consumption Standby: 1.2 W
Quiescent: 6 W
Max: 150 W
Temperature & Humidity External Temperature: 41 to 104°F / 5 to 40°C
Mean Humidity: Less than 75%
Max Humidity: Less than 90%
Dimensions (W × H × D) 6.5 x 17.6 x 7.9" / 166 x 446 x 200 mm
Weight 22.5 lb / 10.2 kg
In the Box
PSI AUDIO A214-M Powered Center-Channel Studio Monitor (Single, Red)
  • Power Cord
  • Individual Frequency-Response Diagram and Data Sheet
  • Set of Anti-Slippage Stickers
  • Limited 5-Year Warranty on Electronics and Transducers
  • Limited 2-Year Warranty on Wooden Cabinet
