Tên thiết bị:  Card âm thanh Focusrite RED 4Pre - Audio Interface with Thunderbolt 2

Model:   Focusrite RED 4Pre

Thương hiệu:  Focusrite

Tình trạng: đóng hộp, hàng mới, sound card, USB cable, thẻ mã kích hoạt phần mềm bản quyền, hướng dẫn sử dụng, chính hãng 100%

Thời gian đặt hàng: 1 - 2 ngày

Hình ảnh thiết bị như hình chụp

Product Highlights

  • 56 Inputs / 64 Outputs
  • 24-Bit / 192 kHz Sampling
  • Four Red Evolution Microphone Preamps
  • Digitally Controlled Preamps
  • Air-Enabled ISA Transformer Modeling
  • High-Quality, Low-Noise AD/DA Converter
  • Low Round-Trip Latency: 1.67 Seconds
  • DigiLink I/O License Included
  • Includes Focusrite Control Software
  • Includes Red and Softube Plug-Ins



Overview:



The Red 4Pre from Focusrite is a 58-input/64-output, high-resolution audio interface with Thunderbolt 2, Pro Tools | HD, and Dante connectivity. The interface offers four Red Evolution microphone preamps, with -129 dBu of EIN and 63 dB of gain providing low noise floors with significant headroom, and includes the "Air" effect, which recreates the sound of transformer-based mic pres from the ISA range. All features of the preamps can be controlled from the front panel or from the included Focusrite Control software. In addition to housing the control surface, the front panel also features three color displays, two 'extended-headroom' 1/4" instrument inputs, and two 1/4" headphone outputs with independent level controls.

The rear panel offers a wide selection of analog connectivity, including 4 XLR microphone inputs, 8 line level inputs via a DB25 connector, 8 line level outputs via a DB25 connector, and a pair of 1/4" monitor outputs. For digital connectivity, the interface offers two sets of optical in/out TOSLINK ports, as well as stereo S/PDIF I/O via RCA jacks. Two DigiLink connectors provide compatibility with Pro Tools | HD interfaces, while the two Thunderbolt 2 ports connect directly to a Mac computer. The two Dante Ethernet ports support audio-over-IP networking for an additional 64 channels. The Red 4Pre also offers both Wordclock and Loop Sync I/O, for connecting any additional digital gear via the BNC connectors.

The Red 4Pre also includes the Softube Time and Tone bundle featuring four plug-ins including Drawmer S73 Intelligent Master Processor, TSAR-1R Reverb, Tube Delay, and Saturation Knob. Also included is the Red Plug-In Suite, which contains accurate models of Focusrite's Red 2 EQ and Red 3 Compressor hardware. The Red 4Pre ships with a 6.6' / 2.0m Thunderbolt cable, an IEC power cord, and software activation codes.



Note: Register a Red 4Pre and you will receive a free Avid Pro Tools | HD DigiLink I/O License from Focusrite.

Versatile Connectivity
  • Thunderbolt 2 connectivity for low round-trip latency, in whatever DAW you use, enabling you to track and overdub with your preferred plug-ins and effects in real time, simplifying your workflow.
  • Connect the Red 4Pre directly and seamlessly into any Pro Tools | HD system, or use it with existing Avid interfaces, thanks to its twin DigiLink connectors.
  • Dual Thunderbolt 2 ports allow daisy-chaining of additional components such as hard drives and displays.
  • The Red 4Pre is network audio-enabled right out of the box, with dual Ethernet ports for Dante audio-over-IP networking, letting you expand your recording capability over Ethernet for up to 64 additional channels anywhere on your network, and with low latency.
  • Additional Red or other Dante-compatible components can be connected to the Ethernet ports of the Red 4Pre to provide additional channels irrespective of the interface used to drive the Red 4Pre.
Red Evolution Air-Enabled Microphone Preamplifiers
  • The Red Evolution mic pres in the Red 4Pre deliver a clear and honest audio performance with -129 dB EIN and 63 dB of gain that allows plenty of room to bring your own sound to life with your choice of external processing
  • The mic pres can be controlled digitally, for adjusting/recalling settings and stereo linking via Focusrite Control software
  • The preamp also includes the ‘Air’ effect, which recreates the sound of the transformer-based mic preamps in the ISA range. When ‘Air’ is enabled, the microphone impedance is set to 2.1 kOhms and the frequency response curve is given a subtle mid-high boost; all in the analog domain
Focusrite's Best Converter Performance
  • The Red 4Pre employs a 'parallel path summing' configuration to lower the noise floor, while utilizing selected high-performance, precision conversion chips for maximized sound quality through premium component selection, advanced design, and optimized board layout.
  • Red 4Pre's converter design strikes a precise balance between multiple factors, including dynamic range, distortion, noise floor, and conversion latency, for the optimal overall sound.
  • With 24-bit/192 kHz sampling capability and 118 dB (A-D) / 121 dB (D-A) dynamic range, it is ideal for high-resolution audio.
  • The Red 4Pre delivers ≤0.0009% THD+Noise and a flat frequency response from 20 Hz to 35 kHz (±0.25 dB or better).
Low Round-Trip Latency
  • Red 4Pre's latency is so low that you can track with your preferred plug-ins and record virtual instruments in real time.
  • This low latency environment simplifies your workflow, allowing you to run a single mix on your DAW for both overdubbing and mixing, with your plug-ins in place, all the time.
Expansion
  • Connect up to 64 additional channels to the Red 4Pre via Ethernet-based Dante networking which provides a simple, single connection carrying both audio and built-in clocking.
  • Whether the Red 4Pre is connected to the computer via Thunderbolt, DigiLink, or Dante, simply connect optional units, such as two RedNet A16R (32 channels of analog I/O), four RedNet MP8R (32 channels of RedNet mic pre), or other Dante-enabled products via Ethernet as desired.
  • Place mic preamps where the music is, and outputs where the sound needs to go – wherever there's an Ethernet connection.
Included Software
  • Red 4Pre includes the Focusrite Control software, providing a straightforward and intuitive way to set up mixes and monitoring, as well as controlling the mic pres – recalling settings, assigning stereo pairs, adjusting gain and enabling features such as high-pass filtering and phantom power.
  • Softube's Time and Tone Bundle is a unique plug-in pack including four of Softube’s professional quality plug-ins:
    • Drawmer S73 Intelligent Master Processor
    • TSAR-1R Reverb
    • Tube Delay
    • Saturation Knob
  • Focusrite Red Plug-in Suite, which accurately models Focusrite’s classic Red range hardware:
    • Red 2 EQ
    • Red 3 Compressor
Connections
  Mic Inputs: 4 x XLR
Instrument Inputs: 2 x 1/4" / 6.35 mm, unbalanced
Line Inputs (1-8): DB25 connector
Line Outputs (3-10): DB25 connector
Monitor Outputs: 2 x 1/4" / 6.35 mm, balanced
Headphone Outputs: 2 x 1/4" / 6.35 mm, stereo
S/PDIF I/O: 2 x RCA
ADAT Optical Input: 2 x TOSLINK ports (1-8 and 9-16)
ADAT Optical Output 2 x TOSLINK ports (1-8 and 9-16)
Avid DigiLink: 2 x Primary port connectors
Thunderbolt: 2 x ports
Wordclock I/O: 1 x BNC input, 1 x BNC output (75 ohm input termination)
Loop Sync I/O: 1 x BNC input, 1 x BNC output
Dante: 2 x Ethernet networking ports
Power: Standard IEC power input
Microphone Inputs Phantom Power: +48 V, switchable per mic input
Frequency Response: 20 Hz to 35 kHz, ±0.2 dB
Signal to Noise Ratio: 118 dB (A-weighted)
Dynamic Range: 118 dB (A-weighted)
THD+N: 0.0009%
Noise EIN: -129 dBu (A-weighted)
Maximum Input Level: +19 dBu
Gain Range: 0-63 dB
Common Mode Rejection Ratio: > 70 dB at 997 Hz (min. gain)
Input Impedance with AIR Mode OFF: 6 kOhms
Input Impedance with AIR Mode ON: 2 kOhms
Line Inputs Line Inputs 1-4
Frequency Response: 20 Hz to 35 kHz, ±0.2 dB
Dynamic Range: 118 dB (A-weighted)
THD+N: 0.0009%
Maximum Input Level: +27 dBu
Gain Range: 0-63 dB

Line Inputs 5-8
Frequency Response: 20 Hz to 35 kHz ±0.2 dB
Dynamic Range: 118 dB (A-weighted)
THD+N: 0.0007%
Maximum Input Level: +26 dBu
Gain Range: Fixed
Instrument Inputs Frequency Response: 20 Hz to 35 kHz, ±0.2 dB
Dynamic Range: 117 dB (A-weighted)
THD+N: 0.0015%
Maximum Input Level: +15 dBu
Gain Range: 0-63 dB
Monitor Outputs Frequency Response: 20 Hz to 35 kHz, ±0.25 dB
Dynamic Range: 120 dB (A-weighted)
Maximum Output Level (0 dBFS): +18 dBu
THD+N: 0.006%
Line Outputs Frequency Response: 20 Hz to 35 kHz, ±0.25 dB
Dynamic Range (Line Outputs): 121 dB (A-weighted)
Maximum Output Level (0 dBFS): +18 dBu
THD+N: 0.0009%
Headphone Outputs Dynamic Range: 115 dB
THD+N: 0.01%
Maximum Output Level: +16 dBu
Sampling Rates 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Mac System Requirements OSX 10.9 Mavericks, 10.10 Yosemite, 10.11 El Capitan
1 x Thunderbolt port or Thunderbolt 2 port
Internet connection for downloading and installing driver.
Power Requirements Input Voltage Range: 100-240 VAC, 50/60 Hz
Max. Power Consumption: 35 W
Dimensions (H x W x D) 1.7 x 19.0 x 13.4" / 44.0 x 483.0 x 340.0 mm
Weight 10.1 lb / 4.59 kg
Packaging Info
Package Weight 15.05 lb
Box Dimensions (LxWxH) 23.8 x 18.6 x 4.5"



In the Box:

Focusrite RED 4Pre - Audio Interface with Thunderbolt 2, Pro Tools, Dante Connections
  • Thunderbolt Cable (6.6' / 2.0m)
  • Software Activation Codes
  • IEC Power Cord
  • Limited 1-Year Warranty
