4710PS-23T-B30-A00 NMB Technologies Corporation | P12890-ND DigiKey Electronics

Product Overview

Digi-Key Part Number	P12890-ND
Quantity Available	194 Can ship immediately
Manufacturer
Manufacturer Part Number	4710PS-23T-B30-A00
Description	FAN AXIAL 119X25.5MM 230VAC TERM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	16 Weeks

Documents & Media

Datasheets	11925PB Series DatasheetAC Fan Part Numbering Guide Fans & Blowers Catalog
Other Related Documents
Product Training Modules	Cooling Solutions Thermal Simulation in Telecom Applications
RoHS Information	4710PS-23T-B30-A00 Material
3D Model	4710PS.stp 4710PS.prt 4710PS.sldprt 4710PS.igs
PCN Part Number
Online Catalog	4710PS Series

Product Attributes	Select All
Category
Family
Manufacturer	NMB Technologies Corporation
Series
Part Status	Active
Voltage - Rated	230VAC
Size / Dimension	Square - 119mm L x 119mm H
Width	25.5mm
Air Flow	70.6 CFM (2.00m³/min)
Static Pressure	0.160 in H2O (40.0 Pa)
Bearing Type	Ball
Fan Type	Tubeaxial
Features	-
Noise	38 dB
Power (Watts)	11.0W
RPM	2700 RPM
Termination	2 Terminals
Ingress Protection	-
Operating Temperature	14 ~ 158°F (-10 ~ 70°C)
Approvals	-
Weight	0.8 lb (362.87g)
Current Rating	0.090A
Voltage Range	-
Material - Frame	Aluminum
Material - Blade	Polycarbonate (PC), Fiberglass Reinforced

THÔNG SỐ KỸ THUẬT

AC Axial Fans

Part Number
Part Details(2)	230	105.9	119	38	Yes
4715HS-22T-B5A-B00 Part Details(2)	220	105.9	119	38	No
4715HS-22T-B50-BM0 Part Details(2)	220	105.9	119	38	No
4715HS-20T-B5A-B00 Part Details(2)	200	105.9	119	38	No
4715HS-20T-B50-BM0 Part Details(2)	200	105.9	119	38	No
Part Details(2)	115	105.9	119	38	Yes
Part Details(2)	115	105.9	119	38	Yes
4715HS-10T-B5A-B00 Part Details(2)	100	105.9	119	38	No
4715HS-10T-B50-BM0 Part Details(2)	100	105.9	119	38	No
Part Details	230	110.0	119	38	Yes
4715FS-23T-B5A Part Details	230	110.0	120	38	No
Part Details	230	110.0	119	38	Yes
Part Details	230	100.0	119	38	Yes
Part Details	230	90.0	119	38	Yes
4715FS-23T-B20 Part Details	230	80.0	119	38	No
Part Details	230	70.0	119	38	Yes
4715FS-23T-B00 Part Details	230	55.0	119	38	No
Part Details	115	110.0	119	38	Yes
Part Details	115	100.0	119	38	Yes
Part Details	115	90.0	119	38	Yes
Part Details	115	80.0	119	38	Yes
Part Details	115	70.0	119	38	Yes
Part Details	115	60.0	119	38	Yes
4710PS-24T-B30-A00 Part Details(2)	240	70.6	119	25	No
4710PS-24T-B20-A00 Part Details(2)	240	53.0	119	25	No
4710PS-23T-B3A Part Details(2)	230	70.6	120	25	No
Part Details(2)	230	70.6	119	25	Yes
Part Details(2)	230	53.0	119	25	Yes
4710PS-22T-B30-B00 Part Details(2)	220	70.6	119	25	No
4710PS-22T-B20-B00 Part Details(2)	220	53.0	119	25	No
4710PS-20T-B30-B00 Part Details(2)	200	70.6	119	25	No
4710PS-20T-B20-B00 Part Details(2)	200	53.0	119	25	No
Part Details(2)	115	70.6	119	25	Yes
Part Details(2)	115	53.0	119	25	Yes
4710PS-10T-B30-B00 Part Details(2)	100	70.6	119	25	No
4710PS-10T-B20-B00 Part Details(2)	100	53.0	119	25	No
3610PS-24T-B30-A00 Part Details(2)	240	34.5	92	25	No
3610PS-24T-B20 Part Details(2)	240	28.0	92	25	No
3610PS-24T-B10-A00 Part Details(2)	240	21.0	92	25	No
Part Details	230	34.5	92	25	Yes
3610PS-23W-B20 Part Details	230	28.0	92	25	No
3610PS-23W-B10 Part Details	230	20.0	92	25	No
Part Details(2)	230	34.5	92	25	Yes
Part Details(2)	230	28.0	92	25	Yes
Part Details(2)	230	20.0	92	25	Yes
Part Details(2)	220	34.5	92	25	Yes
3610PS-22T-B20-B00 Part Details(2)	220	28.0	92	25	No
3610PS-22T-B10-B00 Part Details(2)	220	21.0	92	25	No
3610PS-20T-B30-B00 Part Details(2)	200	34.5	92	25	No
3610PS-20T-B20-B00 Part Details(2)	200	28.0	92	25	No
3610PS-20T-B10-B00 Part Details(2)	200	21.0	92	25	No
Part Details	115	34.5	92	25	Yes
3610PS-12W-B20 Part Details	115	28.0	92	25	No
3610PS-12W-B10 Part Details	115	20.0	92	25	No
Part Details(2)	115	34.5	92	25	Yes
Part Details(2)	115	28.0	92	25	Yes
Part Details(2)	115	20.0	92	25	Yes
Part Details(2)	100	34.5	92	25	Yes
3610PS-10T-B20-B00 Part Details(2)	100	28.0	92	25	No
3610PS-10T-B10-B00 Part Details(2)	100	20.0	92	25	No
3115PS-24T-B30-A00 Part Details(2)	240	32.0	80	38	No
3115PS-24T-B20-A00 Part Details(2)	240	26.5	80	38	No
3115PS-24T-B10-A00 Part Details(2)	240	21.6	80	38	No
Part Details	230	32.0	80	38	Yes
Part Details	230	26.0	80	38	Yes
Part Details(2)	230	32.0	80	38	Yes
Part Details(2)	230	26.0	80	38	Yes
3115PS-23T-B10-A00 Part Details(2)	230	22.0	80	38	No
3115PS-22T-B30-B00 Part Details(2)	220	32.0	80	38	No
3115PS-22T-B20-B00 Part Details(2)	220	25.4	80	38	No
3115PS-22T-B10-B00 Part Details(2)	220	21.2	80	38	No
3115PS-20T-B30-B00 Part Details(2)	200	32.0	80	38	No
3115PS-20T-B20-B00 Part Details(2)	200	24.0	80	38	No
3115PS-20T-B10-B00 Part Details(2)	200	19.4	80	38	No
Part Details(2)	115	32.0	80	38	Yes
Part Details(2)	115	24.0	80	38	Yes
Part Details(2)	115	32.0	80	38	Yes
3115PS-12T-B20-A00 Part Details(2)	115	24.0	80	38	No
3115PS-12T-B10-A00 Part Details(2)	115	19.4	80	38	No
3115PS-10T-B30-B00 Part Details(2)	100	32.0	80	38	No
3115PS-10T-B20-B00 Part Details(2)	100	24.0	80	38	No
3115PS-10T-B10-B00 Part Details(2)	100	19.4	80	38	No
Part Details	230	33.0	80	38	Yes
Part Details	230	28.0	80	38	Yes
Part Details	230	20.0	80	38	Yes
Part Details	230	33.0	80	38	Yes
Part Details	230	28.0	80	38	Yes
Part Details	230	20.0	80	38	Yes
Part Details	115	32.0	80	38	Yes
Part Details	115	27.0	80	38	Yes
Part Details	115	22.0	80	38	Yes
Part Details	115	32.0	80	38	Yes
Part Details	115	27.0	80	38	Yes
Part Details	115	22.0	80	38	Yes
Part Details	115	18.0	80	38	Yes
Part Details(2)	115	19.7	80	25	Yes
3110PS-10W-B30-A00 Part Details(2)	100	19.7	80	25	No
3110MS-24W-B30-A00 Part Details(2)	240	24.0	80	25	No
Part Details(2)	230	24.0	80	25	Yes
3110MS-22W-B30-B00 Part Details(2)	220	24.0	80	25	No
3110MS-20W-B30-B00 Part Details(2)	200	24.0	80	25	No
Part Details(2)	115	20.1	80	25	Yes
Part Details(2)	115	9.1	60	30	Yes
2412PS-10W-B30-B00 Part Details(2)	100	9.1	60	30	No
