Configuration Input voltage Power
ratings		 Output voltage
(VDC)		 Output
current		 Built-in fan Model
Covered Power
Supplies		 100 to 240 VAC
(free)
(80 to 370 VDC *)
S8JX-G15005[][]:
Switchable between 100
to 120 VAC and 200 to
240 VAC. (DC power
cannot be input.)		 15 W 5 V 3 A No S8JX-G01505CD
12 V 1.3 A S8JX-G01512CD
15 V 1 A S8JX-G01515CD
24 V 0.65 A S8JX-G01524CD
48 V 0.35 A S8JX-G01548CD
35 W 5 V 7 A S8JX-G03505CD
12 V 3 A S8JX-G03512CD
15 V 2.4 A S8JX-G03515CD
24 V 1.5 A S8JX-G03524CD
48 V 0.75 A S8JX-G03548CD
50 W 5 V 10 A S8JX-G05005CD
12 V 4.2 A S8JX-G05012CD
24 V 2.1 A S8JX-G05024CD
48 V 1.1 A S8JX-G05048CD
100 W 5 V 20 A S8JX-G10005CD
12 V 8.5 A S8JX-G10012CD
24 V 4.5 A S8JX-G10024CD
48 V 2.1 A S8JX-G10048CD
150 W 5 V 30 A S8JX-G15005CD
12 V 13 A S8JX-G15012CD
24 V 6.5 A S8JX-G15024CD
48 V 3.3 A S8JX-G15048CD
100 to 120 VAC
200 to 240 VAC
(Switchable)		 300 W 5 V 60 A Yes S8JX-G30005CD
12 V 27 A S8JX-G30012CD
24 V 14A No S8JX-G30024CD
48 V 7A S8JX-G30048CD



* The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).

DIN Rail-mounting *

S8JX Lineup 4



Configuration Input voltage Power
ratings		 Output voltage
(VDC)		 Output
current		 Built-in fan Model
Open type Power
Supplies		 100 to 240 VAC
(free)
(80 to 370 VDC *)
S8JX-G15005[][]:
Switchable between 100
to 120 VAC and 200 to
240 VAC. (DC power
cannot be input.)		 15 W 5 V 3 A No S8JX-G01505D
12 V 1.3 A S8JX-G01512D
15 V 1 A S8JX-G01515D
24 V 0.65 A S8JX-G01524D
48 V 0.35 A S8JX-G01548D
35 W 5 V 7 A S8JX-G03505D
12 V 3 A S8JX-G03512D
15 V 2.4 A S8JX-G03515D
24 V 1.5 A S8JX-G03524D
48 V 0.75 A S8JX-G03548D
50 W 5 V 10 A S8JX-G05005D
12 V 4.2 A S8JX-G05012D
24 V 2.1 A S8JX-G05024D
48 V 1.1 A S8JX-G05048D
100 W 5 V 20 A S8JX-G10005D
12 V 8.5 A S8JX-G10012D
24 V 4.5 A S8JX-G10024D
48 V 2.1 A S8JX-G10048D
150 W 5 V 30 A S8JX-G15005D
12 V 13 A S8JX-G15012D
24 V 6.5 A S8JX-G15024D
48 V 3.3 A S8JX-G15048D



* The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).

Front-mounting *

S8JX Lineup 6



Configuration Input voltage Power
ratings		 Output
voltage
(VDC)		 Output
current		 Built-in
fan		 Front-
mounting
bracket		 Model
Covered Power
Supplies		 100 to 240 VAC
(free)
(80 to 370 VDC *)
S8JX-G15005[][]:
Switchable between 100
to 120 VAC and 200 to
240 VAC. (DC power
cannot be input.)		 15 W 5 V 3 A No Provided S8JX-G01505C
12 V 1.3 A S8JX-G01512C
15 V 1 A S8JX-G01515C
24 V 0.65 A S8JX-G01524C
48 V 0.35 A S8JX-G01548C
35 W 5 V 7 A S8JX-G03505C
12 V 3 A S8JX-G03512C
15 V 2.4 A S8JX-G03515C
24 V 1.5 A S8JX-G03524C
48 V 0.75 A S8JX-G03548C
50 W 5 V 10 A S8JX-G05005C
12 V 4.2 A S8JX-G05012C
24 V 2.1 A S8JX-G05024C
48 V 1.1 A S8JX-G05048C
100 W 5 V 20 A S8JX-G10005C
12 V 8.5 A S8JX-G10012C
24 V 4.5 A S8JX-G10024C
48 V 2.1 A S8JX-G10048C
150 W 5 V 30 A S8JX-G15005C
12 V 13 A S8JX-G15012C
24 V 6.5 A S8JX-G15024C
48 V 3.3 A S8JX-G15048C
100 to 120 VAC
200 to 240 VAC
(Switchable)		 300 W 5 V 60 A Yes No S8JX-G30005C
12 V 27 A S8JX-G30012C
24 V 14A No S8JX-G30024C
48 V 7A S8JX-G30048C
600 W 5 V 120A Yes S8JX-G60005C
12 V 53A S8JX-G60012C
24 V 27A S8JX-G60024C
48 V 13A S8JX-G60048C



* The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).

Front-mounting *

S8JX Lineup 8



Configuration Input voltage Power
ratings		 Output
voltage
(VDC)		 Output
current		 Built-in fan Front-
mounting
bracket		 Model
Open type Power
Supplies		 100 to 240 VAC
(free)
(80 to 370 VDC *)
S8JX-G15005[][]:
Switchable between 100
to 120 VAC and 200 to
240 VAC. (DC power
cannot be input.)		 15 W 5 V 3 A No Provided S8JX-G01505
12 V 1.3 A S8JX-G01512
15 V 1 A S8JX-G01515
24 V 0.65 A S8JX-G01524
48 V 0.35 A S8JX-G01548
35 W 5 V 7 A S8JX-G03505
12 V 3 A S8JX-G03512
15 V 2.4 A S8JX-G03515
24 V 1.5 A S8JX-G03524
48 V 0.75 A S8JX-G03548
50 W 5 V 10 A S8JX-G05005
12 V 4.2 A S8JX-G05012
24 V 2.1 A S8JX-G05024
48 V 1.1 A S8JX-G05048
100 W 5 V 20 A S8JX-G10005
12 V 8.5 A S8JX-G10012
24 V 4.5 A S8JX-G10024
48 V 2.1 A S8JX-G10048
150 W 5 V 30 A S8JX-G15005
12 V 13 A S8JX-G15012
24 V 6.5 A S8JX-G15024
48 V 3.3 A S8JX-G15048



* The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC (85 to 264 VAC).
