Cable Length (m)
2
Primary Housing Material
Zinc Alloy Die-Cast
Adjustments
Teach Button
Sensing Beam
Red/Green/Blue LED
Outputs
Bipolar (NPN & PNP)
Connection
Cable
Quick Disconnect Type
No QD
Special Feature: Remote Teach
Yes
Sensing Beam Wavelength
Red: 636 nm; Green: 525 nm; Blue: 472 nm
Max Sensing Range (mm)
10
Power Supply/Supply Voltage
10-30 V dc
Number of Pins
5
LED Orientation
Parallel to sensor length
Indicator
Bargraph
Operation
Light/Dark Operate
Output response time (ms)
0.05
Repeatability (µs)
15
Lens Material
Acrylic
IP Rating
IP67
NEMA Rating
N/A
Max Op. Temperature (°C)
50
Min Op. Temperature (°C)
-10
Max Op. Relative Humidity (%)
90% @ 50°C
Special Feature: Analog Output
No
Delay at Power-up (ms)
1000
Beam Spot Size
1.2 x 3.8 mm at 10 mm
Feature: Timing (Hold/Delay)
Yes
Feature: Quick Disconnect
No
Application: Luminescence
No
Application: Registration Mark
Yes
IO Link
No
Application: Color
No
