Hardware Features
- One 16 port CAT5 KVM switch is integrated in 1U height console, it controls multiple computers via a set of device(LCD monitor, keyboard, mouse)
- Standard RJ-45 connector-Connect to a server or computer via a standard RJ-45 connector with CAT 5e/6 cable
- Supports 1 remote user access to the KVM via network browser with TCP/IP communication protocol
Dual Rail Structure
- The LCD panel and keyboard/touchpad modules slide independently of each other, the keyboard/touchpad module slides back to “hide away” when not in use, while the thin profile LCD monitor rotates back, flush against the rack, allowing administrators to easily monitor computer.
High Performance Touchpad
- Touchpad with trackball- Eliminates the need for a separate, external mouse
Keyboard
- Multi-language support--English, Russian, German, French, Korean, Swedish and Italian, etc.
- Full size 99 keys keyboard with integrated number pad
Security
- Two level password security--only authorized users view and control computers; up to four users and an administrator with a separate profile for each,
- All transmitting data are encrypted with SSL 256 bits and SSL certificate management
Management Way
- Supports 1 remote user access to the KVM via network browser with TCP/IP communication protocol
- Convenient computer switching via front panel LEDs, OSD menu and mouse
- Remote access to the KVM(Keyboard, video and mouse) through modem
- Support any operating system even in BIOS level, during start up or in blue screen
- Supports JAVA browser remote control
- Auto scan feature for monitoring user-selected computers
- Broadcast mode--operations simultaneously performed on all selected computers
Cascade Features
- Directly access and control up to 16 servers with single DL2916i
- By cascading to another 31 switches, as many as 512 servers can be controlled
Wide Compatibility
- Multiplatform support--Windows,Linux and Sun
- Supports server form Lenovo,Hua wei,HP,IBM ,Cisco and Dell, etc.
