Unicode evaluation
Each handle module is highly coded (unicode) The locking module detects only handle modules that have been taught-in. Additional handle modules can be taught-in. Only the last handle module taught-in is detected.
Guard locking type
| MGBS-L1 | Guard locking actuated by spring force applied and power-ON released (closed-circuit current principle) |
Escape release
It is used for manual release of the guard locking without tools in an emergency. The inner door handle permits escape from the danger zone.
Connector assignment
|
Plug connector (view of connection side) |
Pin |
Designation |
Function |
Conductor coloring of connecting cable |
|---|---|---|---|---|
|
|
1 |
IMP |
Operating voltage of guard locking solenoid, 24 V DC |
WH |
|
2 |
UB |
Operating voltage of AP electronics, 24 V DC |
BN |
|
|
3 |
FO1A |
Safety output, channel 1 |
GN |
|
|
4 |
FO1B |
Safety output, channel 2 |
YE |
|
|
5 |
OI |
Diagnostic output |
GY |
|
|
6 |
OD |
Door monitoring output |
PK |
|
|
7 |
0 V UB |
Operating voltage of AP electronics 0 V |
BU |
|
|
8 |
IMM |
Operating voltage of guard locking solenoid, 0 V |
RD |
