Thông Số Kỹ Thuật:

Process Connection   PG13,5
Wetted Parts Stainless Steel 1.4435 EPDM (Ethylene propylene elastomer) Silicone - FDA 21 CFR 177.2600 See compliance details in Material Specification document
Electrical Connector   VP8
Parameter DCO₂ (Dissolved CO2)
Measuring Range 5 - 1000 mbar or 0.5 - 100 % vol or 7.5 - 1500 mg/L in liquid phase at 101.3 kPa and 25°C
Electrolyte None
Accuracy at 25 °C ±5 mbar (5-100 mbar); ±5% (> 100 mbar)
CO₂ Consumption None
Temperature Sensor NTC 22 kOhm
Configurable Values Dissolved CO2 (dCO2): mbar, mmHg, hPa, %-vol, %-sat, µg/l ppb, mg/l ppm; Temperature: K, °C, °F
Surface Quality of Steel Ra < 0.4 µm (N5)
Digital Interface RS485 Modbus (max. 32 addresses)
Baud Rate 4800, 9600, 19200, 38400, 57600, 115200 Bd
Operating Voltage 10 to 27 VDC
Serial Number Yes
Certificate Yes, factory calibration with CO₂ certified gas
Hygienic Design Approval EHEDG approved. EL Class I. (Test executed with Hamilton hygienic socket REF 242545)
ATEX Approval No
IECEx Approval No
Diameter 12 mm
Autoclavable Yes (140°C, 30-minute sterilization duration)
Steam Sterilizable Yes (140°C, 30-minute sterilization duration)
CIP Yes (3% NaOH, 90°C, 30-minute cleaning duration)
Operating Temperature Range -10 to 140 °C; the sensor provides no CO₂ reading above 60 °C
Pressure Range bar g -1 to 12 bar
Protection Rating IP68
Required Flow None
