- Basic data
- Series3
-
Optical data
- Operating range0.0125 ... 0.0165 m
- Light sourceLED, RGB
- Light spot size1.5 mm x 6.5 mm
- Light spot orientationVertical
- Type of light-spot geometryRectangular
- Light beam exitFront
-
Electrical data
- Performance data
- Supply voltage10 ... 30 V, DC
-
Inputs
- Number of teach inputs1 Piece(s)
- Teach input 1
- Teach processStatic 2-point
-
Outputs
- Number of digital switching outputs1 Piece(s)
- Switching output 1
- Switching elementTransistor, PNP
- Switching principleLight/dark reversible
- Performance data
-
Timing
- Switching frequency10,000 Hz
-
Connection
- Connection 1
- Type of connectionConnector
- Thread sizeM8
- MaterialMetal
- No. of pins4 -pin
- Connection 1
-
Mechanical data
- Dimension (W x H x L)11 mm x 32 mm x 17 mm
- Housing materialPlastic, PC-ABS
- Net weight10 g
-
Operation and display
- Operational controlsTeach button
-
Environmental data
- Ambient temperature, operation-30 ... 55 °C
-
Certifications
- Degree of protectionIP 67
- Protection classIII
- Certificationsc UL US
- Standards appliedIEC 60947-5-2
-
Special design
- Special designTeach input, Time function
-
Classification
- Customs tariff number85365019
- eCl@ss 8.027270906
- eCl@ss 9.027270906
- ETIM 5.0EC001820
