Display 15” Wide Viewing Angle (WVA)

Resolution 1024 x 768

Brightness (cd/m2) 350

Contrast Ratio 2500:1

Backlight Type LED

Backlight Life Time >70,000 hrs.

Colors 16.2M

LCD Viewing Angle

(T/B/R/L) 88/88/88/88

Pixel Pitch (mm) 0.297(H) x 0.297(V)

Type 4-wire Resistive Type

Accuracy Active Area Length(X)±2%, Width(Y)±2%

Flash 4 GB

RAM 1 GB

Processor Quad-core RISC

SD Card Slot SD/SDHC

USB Host USB 2.0 x 1

Ethernet LAN 1: 10/100/1000 Base-T x 1

LAN 2: 10/100 Base-T x 1

COM Port

Con.A: COM1 RS-485 2W/4W, COM3 RS-485 2W

Con.B: COM1 RS-232 4W, COM3 RS-232 2W MPI is not supported.

Audio Output Built-in Mono Speaker

Audio Line Out - 3.5 mm jack x 1

Input Power 24±20%VDC

PCB Coating Yes

Enclosure Aluminum

Dimensions WxHxD 366 x 293 x 48.2 mm

Panel Cutout 352 x 279 mm

Weight Approx. 2.74 kg

EasyBuilder Pro V6.05.02 or later versions



=======================
