Display 15.6” Wide Viewing Angle (WVA)

Resolution 1920 x 1080

Brightness (cd/m2) 300

Contrast Ratio 800:1

Backlight Type LED

Backlight Life Time >30,000 hrs.

Colors 16.2M

LCD Viewing Angle (T/B/R/L) 89/89/89/89

Pixel Pitch (mm) 0.17925(H) x 0.17925(V)

Type Tempered Glass, Capacitive Type

Flash 4 GB

RAM 1 GB

Processor Quad-core RISC

USB Host USB 2.0 x 1

Ethernet 10/100 Base-T x 1

COM Port

Con.A: COM1 RS-485 2W/4W, COM3 RS-485 2W

Con.B: COM1 RS-232 4W, COM3 RS-232 2W MPI is not supported.

Audio Output Built-in Mono Speaker

Input Power 24±20%VDC

PCB Coating Yes

Enclosure Front bezel: Plastic, Rear Enclosure: Aluminum

Dimensions WxHxD 400 x 263 x 27.6 mm

Panel Cutout 384 x 247 mm

Weight Approx. 1.6 kg

EasyBuilder Pro V6.06.02 or later versions





=======================
