P20Q Crimping Machine
  Feature description：
● Full Automatic Control with foot pedal
● Quick Change Tool and Die rack
● Energy Saving and Safety Operation
● TUV CE Approved

P20Q  Hydraulic Hose Crimping Machine

Feature description：

● Full Automatic Control with foot pedal
● Quick Change Tool and Die rack
● Energy Saving and Safety Operation
● TUV CE Approved

P20Q  Hydraulic Hose Crimping Machine

Specification：

Main Specification SAMWAY  P20Q
Max Hydraulic Hose 1 1/2’’ 4SP
Crimping Range mm 4-65
Die Type P20
Master Die Length  mm 80
Max Opening   mm +26
Motor KW 4
Crimping Force  KN 1700
Crimpings Per Hour 1800
Control                                                         Control with advanced programmable chip
Foot pedal Included
Die Rack Included
Quick Change Tool Included
Backstop Device Optional
Control by Pressure Optional
Noise Level  dBA 65
Protection Class IP56
L*W*H  mm 680*600*1400
Weight  KG 270

Standard Die Sets Included：

Die No. 10* 12* 14 16 19 22 26 30 34 39 45 51* 57*
Length 55 55 55 55 55 55 75 75 90 90 90 90 90

P20Q  Hydraulic Hose Crimping Machine
