P32D Crimping Machine
  Feature description：
● Digital Precision Control
● Quick Change Tool and Die rack
● Energy Saving and Safety Operation
● TUV CE Approved


P32D Hydraulic Hose Crimping Machine

Feature description：

● Digital Precision Control
● Quick Change Tool and Die rack
● Energy Saving and Safety Operation
● TUV CE Approved

P32D Hydraulic Hose Crimping Machine

Specification：

Main Specification SAMWAY P32D
Max Hydraulic Hose 2" 4SP
Crimping Range mm 4-87
Die Type P32
Master Die Length mm 80
Max Opening  mm +32
Motor KW 4
Crimping Force  KN 2200
Crimpings Per Hour 1200
Control  Digital Control
Foot pedal Included
Die Rack Included
Quick Change Tool Included
Backstop Device Optional
Control by Pressure Optional
Noise Level  dBA 65
Protection Class IP56
L*W*H  mm 680*600*1400
Weight  KG 300

Standard Die Sets Included:

Die No. 10* 12* 14 16 19 22 26 30 34 39 45 51 57 63 69 74* 78*
Length 55 55 55 55 55 55 75 75 90 90 90 90 90 100 100 100 100

* Optional Die Sets Upon Request

Order No.：

220V, 400V, 415V, 440V,480V 3 phase                        :00001310

110V 60hz single phase                                                 :00001311

220V 50/60hz single phase                                           :00001312

P32D Hydraulic Hose Crimping Machine
