Máy ghi âm Tascam DR-701D 6-Track

(0 đánh giá)

Mã SP: Tascam DR-701D
16,990,000 VND

Xuất xứ :Tascam

Nơi rao bán :Toàn quốc

Tình trạng :Mới 100%

Ngày cập nhật :15-07-2019 11:20:03

Bảo hành :12 tháng

Record 4 Channels + Stereo Mix 4 XLR/TRS Inputs with Phantom Power Dual Built-In Omnidirectional Mics Stereo 3.5mm In for Stereo Mic 3.5mm Camera In/Out BNC In for Sync to SMPTE HDMI in Supports Start/Stop from DSLR Writes Time Data to Recorded Audio Files Records Up to 24-Bit/192kHz Mount to DSLR or Tripod

Số lượng:
Mua ngay Thêm vào giỏ hàng

LIÊN HỆ VỚI NGƯỜI BÁN

VNM CO.,LTD

897 Lê Thanh Nghị - TP. Hải Dương

0946112556

product.vnm@gmail.com

http://dienmayviet.com.vn

Ghi chú: GianHangVN không trực tiếp bán sản phẩm, vui lòng liên hệ trực tiếp với người bán bên trên.

>> Hướng dẫn đặt hàng trực tuyến

Giá có thể thay đổi chưa kịp cập nhật, xin vui lòng liên hệ trực tiếp để biết giá

Tên thiết bị:  Máy ghi âm Tascam DR-701D 6-Track

Model:   Tascam DR-70D

Thương hiệu:  Tascam

Tình trạng: đóng hộp, hàng mới, chính hãng 100%

Thời gian đặt hàng: 1 - 2 ngày

Hình ảnh thiết bị như hình chụp



Product Highlights

  • Record 4 Channels + Stereo Mix
  • 4 XLR/TRS Inputs with Phantom Power
  • Dual Built-In Omnidirectional Mics
  • Stereo 3.5mm In for Stereo Mic
  • 3.5mm Camera In/Out
  • BNC In for Sync to SMPTE
  • HDMI in Supports Start/Stop from DSLR
  • Writes Time Data to Recorded Audio Files
  • Records Up to 24-Bit/192kHz
  • Mount to DSLR or Tripod



Overview:



Designed specifically as an audio recording solution for DSLR video applications, the DR-701D 6-Track Field Recorder from Tascam features dual built-in omnidirectional microphones and four XLR/TRS inputs with phantom power and is capable of recording up to 6 tracks simultaneously. It supports a variety of mounting configurations, featuring a 1/4"-20 thread on the bottom for tripod mounting, as well as a removable camera or cage system attachment bracket with a 1/4"-20 screw.



The DR-701D features an HDMI input that can be connected to your camera's HDMI output, allowing you to start and stop recording remotely via the camera's record button if your camera sends HDMI signal triggering. If your camera sends timecode via HDMI, the DR-701D will follow it and write it to the recorded file. Your NLE software will then read that embedded timecode to lock sound and picture together in post. Additionally, audio being recorded on the DR-701D can be added to the incoming video and timecode from the HDMI In port and sent from the DR-701D's HDMI Out to an HDMI monitor recorder. The recorder can also lock to SMPTE timecode coming into its BNC connector.

The DR-701D features a rugged build quality yet weighs less than a pound and a half including the 4 AA batteries that power it. Battery life depends on usage, but with 4 lithium batteries, internal clock, and phantom power on two inputs, the unit is designed to record for over 5 hours at 16-bit/48kHz. The unit can also be powered using the optional PS-P515U AC adapter. Audio is recorded to SD, SDHC, or SDXC cards up to 128 GB and can be recorded at resolutions of up to 24-bit, 192kHz. In addition to the four XLR/TRS inputs, a 3.5mm stereo mini-jack input with optional plug-in power is provided for connecting an external stereo mic.

The recorder also features a camera out mini-jack that allows you to record the output of the DR-701D to your camera to use as a sync reference, and a camera-in mini-jack allows you to playback the camera's audio and monitor from the 3.5mm line out or 3.5mm headphone out jacks.

Note: For a full list of tested cameras and the most current firmware, please visit manufacturer's website.

6 maximum simultaneous recording tracks
SD/SDHC/SDXC cards used for recording media
MONO, STEREO, 2MIX, DUAL MONO, DUAL ST and DUAL2MIX recording modes
Recording formats: 16/24-bit, 44.1/48/96/192kHz (WAV/BWF) (192kHz only for two-track recording)
Built-in original TASCAM HDDA mic preamps provide high audio quality
Input levels can be adjusted separately for each track
XLR/TRS inputs support +4dBu line level and 24/48V phantom power
Clock and record start/stop can be synchronized with a camera using the HDMI port
DR-701D audio signal can be output to an external camera or recorder from the HDMI OUT or line output
Cascade function using HDMI connections allows multiple DR-701D transport and monitoring operations
SMPTE Timecode can be input through the TC IN connector to add recording start times to files
Timecode generator (RTC) allows recording start times to be added to files even when there is no timecode input
Plug-in power mics and high output mics (EXT IN 1/2) supported
CAMERA OUT connector can output audio mixed by the DR-701D to a DSLR camera
CAMERA IN connector enables monitoring the sound from a DSLR camera through the DR-701D
High quality audio output through a line output jack separate from the headphones jack
Headphones jack with 50mW+50mW maximum output
Tripod attachment threads (bottom), camera screw attachment that can be installed or removed with a coin (top) and shoe mount (top) included
Handles on the left and right sides of the front protect the control surface and also enable attachment of a shoulder strap
Transport and SLATE buttons made of rubber suppress noise during operation
HOLD switch prevents inadvertent control adjustments
128×64-dot graphic LCD with backlight
LED lights have high visibility even in direct sunlight
High-speed transfer of files to computers possible using USB 2.0
Micro-B type USB cable included
Powered by 4 AA batteries, USB bus power or a PS-P515U AC adapter (sold separately)
BP-6AA external battery pack (sold separately) enables operation for even longer times
Optional RC-3F foot switch and RC-10 wireless remote control can be connected (both sold separately)
Built-in mixer enables pan and level adjustments as well as solo monitoring and can output a mix of 4 channels
GANG function allows the levels of multiple channels to be controlled simultaneously
Individual channel trim settings shown
5-position low-cut filter (50/80/120/180/220 Hz) cuts unwanted low frequencies
Multi-band limiter automatically adjusts input overloads (stereo-linking possible with 1/L and 2/R)
Delay function can compensate for distances between mics (+/-150 ms)
Mid-side decoder function enables use with mid-side stereo mics
Slate tone insertion functions (AUTO/MANUAL)
Slate tone insertion points can be selected (recording start or recording start and stop when slate AUTO function used)
DR-701D Tested Camera List
HDMI Clock Sync, Start/Stop Trigger & HDMI Timecode Supported Cameras:



  • CANON EOS 5D Mark III
  • Panasonic DMC-GH4
  • SONY α7S
  • SONY α7 II

HDMI Clock Sync & Start/Stop Trigger Supported Cameras (HDMI Timecode Not Supported):

  • Nikon D810




Specifications:Recording Media


Media SD card (64 MB to 2 GB)
SDHC card (4 to 32 GB)
SDXC card (48 to 128 GB)
Recording Format
Recording Format WAV: 44.1/48/96/192 kHz, 16/24-bit
BWF: 44.1/48/96/192 kHz, 16/24-bit
Channels
Number of Channels 4 maximum (stereo × 2, mono × 4)
I/O
Analog Inputs IN 1/2/3/4: XLR-3-31, 1/4" standard TRS jacks (phantom power supplied only to XLR)
EXT IN 1/2: 1/8" stereo mini-jack (can provide plug-in power)
CAMERA IN: 1/8" stereo mini-jack
Analog Outputs PHONES: 1/8" stereo mini-jack
CAMERA OUT: 1/8" stereo mini-jack
LINE OUT: 1/8" stereo mini-jack
HDMI I/O Type A receptacle
USB Connector type: Micro-B
Format: USB 2.0 HIGH SPEED mass storage class
Timecode Input BNC
Remote Input 3/32" (2.5 mm) TRS jack
Power
Power Source 4x AA batteries (alkaline, NiMH or lithium)
AC adapter (TASCAM PS-P515U, sold separately)
External battery pack (TASCAM BP-6AA, sold separately)
Power Consumption 5 W (maximum)
Consumption Current 1 A (maximum)
Battery Operation Time Using alkaline batteries (EVOLTA)
Use conditions:
Channels 1/2 unused
Channels 3/4 use built-in mic
Phantom power off
HDMI not connected
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 3:45

Use conditions:
Channels 1/2 used
Channels 3/4 unused
3mA phantom power used for 2 channels
HDMI not connected
Recording 2ch 48kHz/16-bit WAV files
Operation time: About 2:00

Use conditions:
Channels 1/2 used
Channels 3/4 unused
3mA phantom power used for 2 channels
HDMI input connected (1080/60i)
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 1:30

Using NiMH batteries (eneloop)
Use conditions:
Channels 1/2 unused
Channels 3/4 use built-in mic
Phantom power off
HDMI not connected
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 4:00

Channels 1/2 used
Channels 3/4 unused
3mA phantom power used for 2 channels
HDMI not connected
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 2:30

Channels 1/2 used
Channels 3/4 unused
3mA phantom power used for 2 channels
HDMI input connected (1080/60i)
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 2:00

Using lithium batteries (Energizer ULTIMATE LITHIUM)
Use conditions:
Channels 1/2 unused
Channels 3/4 use built-in mic
Phantom power off
HDMI not connected
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 7:30

Channels 1/2 used
Channels 3/4 unused
3mA phantom power used for 2 channels
HDMI not connected
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 6:30

Channels 1/2 used
Channels 3/4 unused
3mA phantom power used for 2 channels
HDMI input connected (1080/60i)
Recording 2ch 48 kHz/16-bit WAV files
Operation time: About 3:30

NOTE: When using phantom power, the operation time might be reduced depending on the mic being used
Audio Performance
Frequency Response 20 Hz - 20 kHz +0.5/-1 dB (LINE IN or MIC IN to LINE OUT, 44.1/48kHz sampling frequency, JEITA)
20 Hz - 40 kHz +0.5/-1 dB (LINE IN or MIC IN to LINE OUT, 96kHz sampling frequency, JEITA)
20 Hz - 80 kHz +0.5/-5 dB (LINE IN or MIC IN to LINE OUT, 192 kHz sampling frequency, JEITA)
Distortion 0.007% or less (LINE IN or MIC IN to LINE OUT, 44.1/48/96/192kHz sampling frequency, JEITA)
Signal to Noise Ratio 100 dB or more (LINE IN or MIC IN to LINE OUT, 44.1/48/96/192kHz sampling frequency, JEITA)
Equivalent Input Noise -124 dBu or lower
Recording Time WAV/BWF 16-bit (Stereo) 44.1 kHz: 6:17
WAV/BWF 24-bit (Stereo) 96 kHz: 1:55
WAV/BWF 24-bit (Stereo) 192 kHz: 0:57

(SDHC card capacity 4 GB)
General
Operating Temperature 32 to 104°F (0 to 40°C)
Dimensions (W × H × D) With top adapter attached: 6.7 x 2.3 x 4.5" (169.0 x 57.3 x 113.5 mm)
Weight With Batteries: 23.1 oz (654.0 g)
Without Batteries: 19.8 oz (561.0 g)
Packaging Info
Package Weight 2.0 lb
Box Dimensions (LxWxH) 9.9 x 7.2 x 4.2"



In the Box:

Tascam DR-701D 6-Track Field Recorder for DSLR with SMPTE Timecode
  • USB Cable
  • 6 x Camera Attachment Bracket Screw Hole Covers
  • Limited 1-Year Warranty
