Tên thiết bị:  Roland V-8 Eight Channel Live Video Effects Switcher

Model:   Roland V-1HD

Thương hiệu:  Roland

Tình trạng:  hàng mới

    8 Channels
    Composite, Component and Y/C Input
    Preview Out
    PC Input

Roland V-8 Overview

The Edirol/Roland V-8 is a powerful, easy to use eight-channel video mixer capable of switching between eight cameras or video tape decks during a live performance with smooth transitions and special effects. The V-8 is an affordable solution for the video needs of houses of worship, schools, and nightclubs.

High Quality Digital Signal Processing

Video sources are processed completely in the digital domain for professional video quality (13.5MHz, 8-bit, 4:2:2). The V-8 is ideal for use on large screens, and because the internal processing is digital there is no quality loss to the output signal.

Two Channel TBC / Frame Synchronizer

Input sources go through independent two-channel TBC (Time Base Correction) circuits and two-channel frame synchronizers to ensure smooth transitions and stable images.

Two-Channel Digital Effects

The V-8 features two independent channels of video effects that include a rich selection of digital effects including colorize, strobe, mirror, multi-screen, negative, field freeze, frame freeze, solarize and color filter. The V-8 also features composition effects such as picture-in-picture, chroma key, and luminance key. A single button press can recall the effects.

Preview Function and On-Screen Menu

The V-8's preview function is controlled by the source selection button, and allows monitoring of each of the four input sources or the output source before transition, to a single preview monitor.

Memory Function

The V-8's memory function allows the memorization and convenient recall of panel settings, such as effect assignment to each button. The memory stores up to eight configurations and keeps stored settings even with the power off.

Synchronization with MIDI Equipment

The V-8 features video transitions and effects that can be synchronized with MIDI. The BPM (beat per minute) of transitions and effects can be made to follow the beat of a music track by using the TAP function. The functions of the V-8 can also be controlled via MIDI equipment such as a MIDI keyboard controller.


Roland V-8 Specs

Video System:NTSC or PAL
Sampling:13.5MHz, 4:2:2 (Y:B-Y:R-Y), 8-bit
Audio n/a
Input and Output Connectors Video In:
Composite x8, on BNCs
Y/C S-Video x4, on 4-Pins
VGA/Component x2, on HD-15s
Video Out:
Composite x2 on BNCs
Y/C x1, on a 4-Pin
Preview Out: x1 RCA
MIDI In x1 MIDI Out/Through x1
Power Requirements 9VDC Power Supply (Included)
Power Consumption 18 watts
Dimensions (WxHxD) 9 3/8 x 5 5/16 x 12 7/16"
238 x 134 x 315mm
Weight 7 lbs
3.2kg

In the Box

  • Roland V-8 Eight Channel Live Video Effects Switcher
  • 9V DC Power Supply
  • Power Cord
  • 90-Day B&H Used Warranty
