- Basic data
- Series403
-
Timing
- Switching frequency15 Hz
-
Electrical data
- Protective circuitShort circuit protected, Polarity reversal protection
- Performance data
- Supply voltage18 ... 31.2 V, DC
-
Outputs
- Switching outputs
- TypeDigital switching output
- Voltage typeAC/DC
-
Switching output 1
- Switching elementRelay, NC contact/NO contact
- Switching principleNC contact/NO contact
-
Switching output 2
- Switching elementRelay
- Switching elementNC contact/NO contact
- Switching principleNC contact/NO contact
- Switching outputs
-
Interface
- TypeNAMUR
-
Connection
- Number of connections3 Piece(s)
- Connection 1
- Type of connectionTerminal
- No. of pins3 -pin
-
Connection 2
- Type of connectionTerminal
- No. of pins3 -pin
-
Connection 3
- Type of connectionTerminal
- No. of pins3 -pin
-
Connection 4
- Type of connectionTerminal
- No. of pins3 -pin
-
Mechanical data
- DesignCubic
- Dimension18 mm x 99.5 mm x 112 mm
- Housing materialPlastic, PA 66
- Net weight160 g
- Housing colorGray
- Type of fasteningInstallation on DIN rail
-
Operation and display
- Type of displayLED
- Number of LEDs3 Piece(s)
-
Environmental data
- Ambient temperature, operation-20 ... 70 °C
- Ambient temperature, storage-40 ... 80 °C
-
Ex specification
- Ex device groupII
- Ignition protection type“ia” intrinsically safe
-
Certifications
- Degree of protectionIP 20 (terminals), IP 30 (housing)
- CertificationsEx
- Standards appliedEN 61326-1
- Ex-standardEN 50014, EN 50020, EN 50021, EN 50281-1-1, EN 50284
-
Classification
- Customs tariff number85365019
- eCl@ss 8.027279214
- eCl@ss 9.027069190
