CHARACTERISTICS
- Pressure type
- relative
- Technology
- thin-film
- Output
- 4-20 mA
- Mounting
- threaded
- Fluid
- for gas, for liquids
- Material
- stainless steel, steel
- Protection level
- IP65, IP67, rugged, EMC
- Other characteristics
- two-wire, compact, CE, temperature-compensated, high-temperature, fast response time, fully-welded, high-resolution, multifunction, with pulse-snubber, miniature
- Applications
- for refrigeration circuits, for water treatment, for OEM
- Process temperature
-
Max.: 125 °C (257 °F)
Min.: -40 °C (-40 °F)
- Pressure range
-
Max.: 600 bar (8,702.26 psi)
Min.: 0 bar (0 psi)
DESCRIPTION
Main features Measuring accuracy 0.3 % Completely welded steel sensor system without additional seals Excellent long-term stability Optional: 5-fold overpressure resistance Optional: Switching output 1 or 2 PNP transistors About The pressure transmitter NAH 8254 with increased accuracy of 0.3% and optional switching outputs has an exceptionally long-term stable thin-film-on-steel sensor cell with triple (optionally 5-fold) overpressure protection. The robust design and the wide temperature range of -40°C to +125°C make the NAH 8254 the ideal solution when pressure needs to be measured accurately and reliably under rough environmental conditions.
