Màn hình LCD : 7'TFT
Đèn nền: LED
Màu hiển thị: 65535 màu sắc
Độ phân giải: 800*480px
Độ sáng màn hình: 250cd/m2
Màn hình cảm ứng: Điện trở
Nguồn cấp định mức: 24±20%VDC
Công suất định mức: 5W
Bộ xử lý: 4 lõi, 800 MHz
Memory: 256M
Storage devices: 128M
Phần mềm lập trình: MCGSPRO
Cổng giao tiếp
+ COM1 (RS232), COM2 (RS485), COM3 (RS485), COM4 (RS485)
+ COM1 (RS232), COM9 (RS422)
+ Cổng USB
+ Cổng máy in
+ Cổng Ethernet
Mặt cắt tủ: 215*152
================================
|
size |
model number |
resolution ratio |
hole size |
dominant frequency |
Memory |
storage |
serial interface |
Ethernet |
color |
notes |
|
7 inches |
TPC7062TX(KX) |
800*480 |
215*152mm |
600MHz |
128M |
128M |
RS485*2RS232*1 |
/ |
grey |
Old version software |
|
TPC7062Ti |
800*480 |
215*152mm |
600MHz |
128M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7012EL |
800*480 |
192*138mm |
600MHz |
64M |
8M |
RS485*2RS232*1 |
/ |
grey |
MCGSPRO Upgrade Configuration Software |
|
|
TPC7022ES |
800*480 |
192*138mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
/ |
white |
||
|
TPC7022Et |
800*480 |
215*152mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
/ |
grey |
||
|
TPC7022EW |
800*480 |
192*138mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7022EX |
800*480 |
215*152mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC7032KW |
800*480 |
192*138mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
/ |
white |
||
|
TPC7032Kx |
800*480 |
215*152mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
/ |
grey |
||
|
TPC7032Ki |
800*480 |
192-138mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7032Kt |
800*480 |
215*152mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC7072Gi |
800*480 |
192*138mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7072Gt |
800*480 |
215*152mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
10 inches |
TPC1061TD |
1024*600 |
261*180mm |
600MHz |
128M |
/ |
RS485*1RS232*1 |
LAN*1 |
grey |
Old version software |
|
TPC1061Ti(TX) |
1024*600 |
261*180mm |
600MHz |
128M |
128M |
RS485*1RS232*1 |
LAN*1 |
grey |
||
|
TPC1021Et |
1024*600 |
261*180mm |
800MHz |
64M |
8M |
RS485*1RS232*1 |
LAN*1 |
grey |
MCGSPRO Upgrade Configuration Software |
|
|
TPC1021Ei |
1024*600 |
260-202mm |
800MHz |
64M |
8M |
RS485*1RS232*1 |
LAN*1 |
Cast aluminum |
||
|
TPC1031Kt |
1024*600 |
261*180mm |
800MHz |
256M |
128M |
RS485*1RS232*1 |
LAN*1 |
grey |
||
|
TPC1031Ki |
1024*600 |
260-202mm |
800MHz |
256M |
128M |
RS485*1RS232*1 |
LAN*1 |
Cast aluminum |
||
|
TPC1071Gt |
1024*600 |
261*180mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC1071Gi |
1024*600 |
260-202mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
Cast aluminum |
||
|
15 inches |
TPC1570Gi |
1920*1080 |
384*247mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
Cast aluminum |
|
|
7-inch Internet of Things |
TPC7022Ni-Wi |
800*480 |
192*138mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
|
|
TPC7022Ni-4G |
800*480 |
192*138mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7022Nt-Wifi |
800*480 |
215*152mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC7022Nt-4G |
800*480 |
215*152mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC1021Nt-Wifi |
1024*600 |
261*180mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC1021Nt-4G |
1024*600 |
261*180mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
