Nguồn cấp: 24VDC
LCD hiển thị: 7 inch TFT
Độ phân giải (WxH dots): 800×480
Độ sáng (cd/m2): 200
Tuổi thọ LCD: >30,000 hr.
Màn hình LCD: 65500 màu
Cảm ứng: 4-wire Resistive Type
Bộ nhớ(MB): 128
RAM (MB): 128
USB Host: USB 2.0 x 1
USB Client:
RTC Built-in
Ethernet: 10/100M
COM1 RS-232, COM2 RS-485 2W/4W
Kích thước tủ 192 × 138
================================
|
size |
model number |
resolution ratio |
hole size |
dominant frequency |
Memory |
storage |
serial interface |
Ethernet |
color |
notes |
|
7 inches |
TPC7062TX(KX) |
800*480 |
215*152mm |
600MHz |
128M |
128M |
RS485*2RS232*1 |
/ |
grey |
Old version software |
|
TPC7062Ti |
800*480 |
215*152mm |
600MHz |
128M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7012EL |
800*480 |
192*138mm |
600MHz |
64M |
8M |
RS485*2RS232*1 |
/ |
grey |
MCGSPRO Upgrade Configuration Software |
|
|
TPC7022ES |
800*480 |
192*138mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
/ |
white |
||
|
TPC7022Et |
800*480 |
215*152mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
/ |
grey |
||
|
TPC7022EW |
800*480 |
192*138mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7022EX |
800*480 |
215*152mm |
800MHz |
64M |
8M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC7032KW |
800*480 |
192*138mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
/ |
white |
||
|
TPC7032Kx |
800*480 |
215*152mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
/ |
grey |
||
|
TPC7032Ki |
800*480 |
192-138mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7032Kt |
800*480 |
215*152mm |
800MHz |
256M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC7072Gi |
800*480 |
192*138mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7072Gt |
800*480 |
215*152mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
10 inches |
TPC1061TD |
1024*600 |
261*180mm |
600MHz |
128M |
/ |
RS485*1RS232*1 |
LAN*1 |
grey |
Old version software |
|
TPC1061Ti(TX) |
1024*600 |
261*180mm |
600MHz |
128M |
128M |
RS485*1RS232*1 |
LAN*1 |
grey |
||
|
TPC1021Et |
1024*600 |
261*180mm |
800MHz |
64M |
8M |
RS485*1RS232*1 |
LAN*1 |
grey |
MCGSPRO Upgrade Configuration Software |
|
|
TPC1021Ei |
1024*600 |
260-202mm |
800MHz |
64M |
8M |
RS485*1RS232*1 |
LAN*1 |
Cast aluminum |
||
|
TPC1031Kt |
1024*600 |
261*180mm |
800MHz |
256M |
128M |
RS485*1RS232*1 |
LAN*1 |
grey |
||
|
TPC1031Ki |
1024*600 |
260-202mm |
800MHz |
256M |
128M |
RS485*1RS232*1 |
LAN*1 |
Cast aluminum |
||
|
TPC1071Gt |
1024*600 |
261*180mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC1071Gi |
1024*600 |
260-202mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
Cast aluminum |
||
|
15 inches |
TPC1570Gi |
1920*1080 |
384*247mm |
1GHZ |
512M |
4G |
RS485*2RS232*1 |
LAN*1 |
Cast aluminum |
|
|
7-inch Internet of Things |
TPC7022Ni-Wi |
800*480 |
192*138mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
|
|
TPC7022Ni-4G |
800*480 |
192*138mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
white |
||
|
TPC7022Nt-Wifi |
800*480 |
215*152mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC7022Nt-4G |
800*480 |
215*152mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC1021Nt-Wifi |
1024*600 |
261*180mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
||
|
TPC1021Nt-4G |
1024*600 |
261*180mm |
800MHz |
64M |
128M |
RS485*2RS232*1 |
LAN*1 |
grey |
