Thông số kỹ thuật:

Capacity
Self-pumping throughputs of up to 200,000 litres/hr.
No Bypassing
Product cannot bypass the precision rotor/stator workhead.
Interchangeable Workheads
Single stage rotor/stator configurations as standard. For those applications that require greater shear, interchangeable multistage configurations can be used.
Materials of Construction
Product contact parts in 316L stainless steel. Special materials available on request.
Motor Specifications
​TEFV and ATEX approved Flameproof motors are available as standard. Inverter rated, stainless steel and other motors are available as optional extras.
Inlet and Outlet Connections
All sanitary or flange fittings available upon request (i.e., Tri-Clamp, ASA, DIN, etc). All Silverson In-Line Mixers are designed for cleaning-in-place (CIP and SIP).



Tùy chọn:

    Model        kW      R.P.M      TEFV A      ATEX A     TEFV B    ATEX B    C     D     E      Inlet/ Outlet
275LS 1.5 3000 524 518 140 230 98 133 167 38
425LS 4 3000 692 702 189 289 129 181 225 50
450LS 7.5 3000 692 702 189 289 129 181 225 50
600LS 15 3000 911 911 239 316 156 213 284 75
700LS 37 3000 1227 1177 325 370 203 330 479 100
