CHARACTERISTICS
- Pressure type
- relative
- Technology
- ceramic
- Output
- 4-20 mA
- Mounting
- immersed
- Material
- stainless steel
- Protection level
- IP68
- Other characteristics
- two-wire, CE, fast response time, with pulse-snubber, multifunction
- Applications
- for water treatment
- Process temperature
-
Min.: -25 °C (-13 °F)
Max.: 80 °C (176 °F)
- Pressure range
-
Min.: 0 Pa (0 psi)
Max.: 1,000,000 Pa (145.04 psi)
DESCRIPTION
Main features Good media compatibility Economical Cable PUR/PE or FEP Lightning protection integrated The Submersible Pressure Transmitter ECL is based on Trafag’s own thick-film-on-ceramic technology. Together with the inhouse developed high performance ASIC chip electronics it ensures a high level of accuracy over a wide temperature range.
