CHARACTERISTICS
- Pressure type
- relative
- Technology
- thin-film
- Output
- 4-20 mA
- Mounting
- threaded
- Fluid
- for gas, for liquids
- Material
- stainless steel
- Protection level
- IP65, IP67, IP68, rugged, EMC
- Other characteristics
- high-temperature, two-wire, CE, high-overpressure, temperature-compensated, fast response time, with pulse-snubber, fully-welded, multifunction
- Applications
- for OEM
- Process temperature
-
Max.: 125 °C (257 °F)
Min.: -40 °C (-40 °F)
- Pressure range
-
Max.: 600 bar (8,702.26 psi)
Min.: 0 bar (0 psi)
DESCRIPTION
Main features Excellent long-term stability Completely welded steel sensor system without additional seals Accuracy classes 0.3%, 0.5% Optional: 5-fold overpressure resistance Optionally with housing material AISI316L About The industrial pressure transmitter EPI 8287 features the extremely robust and stable thin-film-on-steel sensor element from its well-proven predecessor EPI 8297. In combination with the new inhouse developed ASIC TX it offers a wide temperature range up to 125°C and triple overpressure safety which makes it the perfect solution for a wide range of demanding applications.
