| Technical data - electrical ratings | |
|---|---|
| Voltage supply | 4.75...30 VDC |
| Consumption typ. | 100 mA (24 VDC, w/o load) |
| Pulses per revolution | 100...25000 |
| Sensing method | Optical |
| Output frequency | ≤300 kHz |
| Output signals | A 90° B |
| Output stages | Push-pull antivalent, short-circuit proof (HTL) |
| Interference immunity | DIN EN 61000-6-2 |
| Emitted interference | DIN EN 61000-6-3 |
| Technical data - mechanical design | |
| Size (flange) | ø40 mm |
| Shaft type | ø6 mm solid shaft |
| Protection DIN EN 60529 | IP 64 |
| Operating speed | ≤3000 rpm |
| Operating torque typ. | 0.0075 Nm (3000 rpm / 20 °C) |
| Materials | Encoder housing: aluminium Measuring arm: Aluminium/steel Measuring wheel: Aluminium/NBR |
| Operating temperature | -20...+85 °C |
| Relative humidity | 95 % non-condensing |
| Resistance | DIN EN 60068-2-6 Vibration 10 g, 10-200 Hz DIN EN 60068-2-27 Shock 50 g, 11 ms |
| Connection | Connector M12, 8-pin Cable 2 m |
| Weight approx. | 100 g |
| Data type | Design | Download | Size |
|---|---|---|---|
| Data sheet | MA20 |  | | |
333 kb |
| Sample picture | Product family | Description |
|---|---|---|
Connectors and cables |
Female connector M12, 8-pin, straight, without cable |
